|Place of Origin:||China|
|Certification:||CE / ISO9001|
|Model Number:||RNCF2066 / RNCF2066S|
|Minimum Order Quantity:||1 Lane|
|Packaging Details:||carton and wooden packing|
|Delivery Time:||7-15 working days|
|Supply Ability:||2000 units Per Month|
|Materials:||304# Stainless Steel||Finish:||Brushed Surface/polishing Surface|
|Dimension:||1406*300*1023mm||Power Voltage:||AC220V±10%, 50Hz±10%|
|Driver Motor:||Brush Motor||Passing Speed:||30~40 Persons/min|
|Passage Width:||600mm~900mm||Operation Temperature::||-10℃ ~ +70℃|
waist high turnstile,
urnstile access control
Introduce of sliding turnstile gates :
Intelligent Entrance Gates Electronic security turnstile sliding gate / full height flap turnstile for building
Appearance (304) stainless steel plate stamping molding,nice shape,rust-proof and durable.Besides foreign standard electrical interface,bar code,ID card,IC card reader can be integrated in the equipment. They are used most commonly in train stations, airports, theme parks, museums and office lobbies.
Functions and Features of the sliding gates :
1. Problem-self-checking function.
2. Many options of working ways: bi-direction card reading; one direction card reading and another no reading; one direction card reading and another freely. And single direction photocell controlled passing and close. Working ways can be set in the control panel.
3. When power off, arm open automatically and power on again, arm will be held automatically.
4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel.
5. Auto-reposition function: After card read, passenger not pass within regulated time period, full-height turnstile will cancel this passing right. And the regulated time period for passing can be set by managers.
6. If passenger pass without card read or valid card read, flap barrier will alarm untill passenger get back from the flap barrier and then take a valid card to be read for passing.
7. Flap barrier is with 485 interface for long-distrance control concern.
8. Anti-rush function: if there is no open single, arm will be holding tightly.
9. Double anti-clipping function: photocell anti-clipping and mechanical anti-clipping.When passenger is going through the flap barrier, photocell will detect out this situation and will not close. After passenger passed, arm will close automatically. During its reposition, if arm meets any obstacle, arm will get back automatcially or stop working for a while with very slight force. Also it will alarm.
10. Flap barrier is with standard electrical interface for the integration of various readers and writers.
11. Flap barrier can count how many passenger has passed and will show it in the LED display.
12. Direction display to guide passenger which direction is to go.
13. Card-reading with memory or without memory function.
14. Flap barrier can control the population inside in the control of software.
15. Stable running with little noise.
|Structure||frame structure/standard stainless steel shell|
|Production||full CNC laser cutting machine production|
|Maximum channel width||600mm|
|Drive motor||stepping motor|
|Power on state require time||3 seconds|
|Failure automatically reset time||10 seconds|
|Passing speed||<=40 persons/min|
|Special Design||OEM is welcome,to meet your needs as best as we can|
|Warranty||12 months after shipped,the destruction of the non-human factos will be covered.|
|Technical Service||Product related issues,we will provide comprehensive after-sales guidance and help.|
|Operating Temperature||-10°C ~ 70°C, <=95%|
|Package||Paper Carton/Wooden Box|
|Payment terms||T/T,west union,L/C|
|Leading time||3-7working days for sample|
