Shenzhen RONA Intelligent Technology Co., Ltd
RONA Intelligent Technology Co., Limited
 |
| Place of Origin: | China |
| Brand Name: | RONA |
| Certification: | CE / ISO9001 |
| Model Number: | RNCF H1066R |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Export Wooden Packing |
| Delivery Time: | 7-15 work days |
| Payment Terms: | T/T, L/C, |
| Supply Ability: | 2000 units Per Month |
| Origin: | Guangdong, China (Mainland) | Size: | 1400L*(250-300)W*1020H(mm) |
|---|---|---|---|
| Item: | Sliding Barrier Turnstile | Framework: | 304 Grade Stainless Steel |
| Swing Arm Material: | Stainless Steel | Transit Speed: | 30 Persons/min |
| Color: | Red (Customized) | Infrared Sensor: | 5~11 Pair |
| Name: | Stainless Steel Security Passage Turnstile With IR Sensor,Alarm Sliding Flap Turnstile Barrier | ||
| High Light: | automatic systems turnstiles,waist high turnstile |
||
Stainless Steel Security Passage Turnstile With IR Sensor,Alarm Sliding Flap Turnstile Barrier
| Description | Parameters |
| Item / Model | RNCF H1066B-2 |
| Power voltage | AC220±10%,50Hz |
| Drive voltage | DC24V 20W |
| Pass Speed | not more than 30 persons/minutes |
| Open direction | Unidirectional and bi-directional (optional) |
| Opening time | 0.6S/adjustable |
| Humidity | ≤90% coagulation free |
| Material Thickness | 2.0mm(Optional) |
| Length of the bar | 230~900mm |
| Way | One-Way / Two-Way |
Product Description
| 1. Illegal Alarm Function | Break-in ,tail ,over-pass and reverse alert function in order to keep orderliness and effective manage |
| 2. Anti-pinch function | Anti-trailing function, the turnstile will lock if someone wants to burst in without swiping the RFID card. |
| 3. Housing | 304 Stainless Steel(Light Wire Drawing Type) |
| 4. Emergency-escape function | The obstacles will open automatically by pressing the emergency button which can be remote-controlled whether the power is on or not |
| 5.Standard input/output port | Meanwhile leaving a port space for installing RS485 communication, connect and manage the integrated systems through the remote PC |
| 6.Control Software | Access Control System / Electronic Ticketing System / Consumer System, Etc. |
Standard functions & features of Sliding Turnstiles Gate
1. Kinds Of Mode Alarm Function, Including Illegal Intrusion, Anti Intrusion, Trailing, Traffic Alarm, Etc.
2.Anti Impact Function, In The Absence Of The Received Gate Signal, Automatically Block Arm Lock Or Alarm
3. Normally Open, Normally Closed Mode Can Be Adjusted, Easily Through The Dial Code Or External Manual Button Control
4. Flexible Access Indication Function, High Brightness Indicator Light And The Human Nature Of The Prompt Function, Let The Channel More Features
5. A Variety Of Traffic Patterns Can Be One-Way Or Two-Way Control Personnel, Or One-Way Controlled, Reverse Free Access.
6. Mechanical, Infrared Double Anti Pinch Function, In Arms Reduction Process Blocked In The Block, Automatic Stop Or Rebound, And Send Out Alarm Signals;
Extended functions
| 1. | Counting Function |
| 2. | LED counting function |
| 3. | Voice prompt function |
| 4. | Barrier color can choose |
| 5. | Secondly opening function to meet ticket system and anti-passback function |
Delivery
Contact Person: Joey Tu
Tel: 0086-88853586 ext 8018
