Place of Origin: | China |
Brand Name: | RONA |
Certification: | CE/ISO9001 |
Model Number: | RNCF P858 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiation |
Packaging Details: | carton and wooden packing |
Delivery Time: | 7-15 work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 2000 unit per month |
Material: | 304 Stainless Steel | Warranty: | One Year |
---|---|---|---|
Size: | L1400mm*W220mm*H980mm | Passing Speed: | 25-30 Person/min |
Passage Width: | 550mm | Housing Material: | 304 Stailess Steel |
Normal Running Life: | 10 Million Times | ||
High Light: | waist height tripod security gates,face recognition tripod security gates,scenic area vertical tripod turnstile |
Product Description
1. Optical turnstile is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions. |
2. The body is made from brushed stainless steel which creates a seamless and elegant access point to blend into most indoor environment. |
3. It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint and Biometric device). |
4. In case of emergency, the Optical Turnstile arm will open automatically to allow free passage. |
5. Optical Turnstiles are suit for elegant and luxury entrance solutions. |
1.Semi-auto mode: After reading card the passenger pushes the arm by hand until he goes through the barriers and the arm arrives in home position.
2. Full-auto mode: The passenger pushes the arm at a little strength after reading card, and the arm will automatically rotate forward by motor power until the arm arrives in home position.
3.Tripod turnstile is ideal for both indoor and outdoor settings.
4.It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint and Biometric device).
5.In case of emergency, the turnstile horizontal arm will drop down to allow free passage when power off.
6. Single or bi-directional function in mechanical and electrical versions.
7. Automatic reset of barrier arms after each passage.
8. Cable or wireless remote control panel key override control for emergency situations. Automatically arm drop down when power off or emergency.
9. Adjustable time out delay.
Technical parameters
Description | Parameters |
Item / Model | RNCF P858 |
Running life | >10 million |
Working voltage | AC220±10% 50hz 50w |
Max bearing stress of arm | 80KG |
Open direction | Unidirectional and bidirectional (optional) |
Opening time | 0.3S(adjustable) |
Humidity | ≤90% coagulation free |
Thickness of Housing | 2.0mm |
Length of the bar | 230-900mm |
Passage width | 550mm |
Swing arm work angle | 180° |
Adaptive Place
1. Office: Business Building, Government Office, Etc.;
2. Science And Education Unit: Colleges And Universities, Research Institutes, Libraries, Etc.;
3. Business Services: Supermarkets, Shopping Malls, Hotels, Clubs, Banks, Etc.;
4. Leisure And Entertainment Venues: Parks, Scenic Spots, Amusement Parks, Etc.
5. Transport Site: Bus Station, Railway Station, Subway Station, Airport And So On.
