2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod

2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod

  • 2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod
  • 2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod
  • 2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod
  • 2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod
2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod
Product Details:
Place of Origin: China
Brand Name: RONA
Certification: CE / ISO9001
Model Number: RNCF238 (NEW)
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: carton and wooden packing
Delivery Time: 7-15 working days
Payment Terms: T/T,
Supply Ability: 2000 units Per Month
Contact Now
Detailed Product Description
Framework Material: 304# Stainless Steel Dimension: 420L*330W*990H Mm
Stretching Out Arm Length: 500mm Passing Speed: 30 Persons/min
Passage Width: 550mm Mean Time To Failure: Min. 5 000 000
Relative Humidity: ≤95% Not Condensed Working Environment: Indoor Or Outdoor
High Light:

pedestrian turnstile gate

,

tripod access system

2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod



Basic Information
  • Model NO.: RNCF238 (NEW)
  • Sensing Method: Electric
  • Application: Access Control System
  • Movement: Single Movement
  • Type: Three Roller Gates
  • Control Mode: Automatic
  • Communication Interface: RS485, TCP/IP
  • Housing Size: 420L*330W*990H mm
  • Housing Material: 304 Grade Stainless Steel Optional
  • Passing Speed: 30-45 Person/Min
  • Working Voltage: AC220V±10V, 50Hz
  • Control Type: IC/ID/Barcode Control Accepted
  • Boom Length: Less Than 700mm
  • Direction: Single or Bi-Directional
  • Operating Humidity: ≤90% Non-Condensing
  • Working Temperature: Single or Bi-Directional
  • Operation Life: More Than 5 Million Times
  • Trademark: RONA
  • Transport Package: Export wooden pakage
  • Specification: CE; ISO9001: 2008; SGS
  • Origin: China



TECHNICAL SPECIFICATIONS:

Framework: 304# Stainless Steel(default), 316# Stainless Steel or Paint (optional)
Thickness of ply: 1.3mm (default)
Finish: ① stainless steel surface: brushed surface, polishing surface (default) or anti-fingerprint surface (optional); ② painted surface: any color surface or anti-fingerprint surface (optional)
Dimension(L*W*H): 420mm*330mm*990mm (default)
Arm material: Steel
Arm length: 500mm
Arm diameter: 38mm
The maximum tolerance of the pole: 80Kg
Working driving force of the pole: 3Kg
Read facilities mounting: may be mounted on the surface of turnstile, or flush mounted, or rack mounting. There is an output to interlock the Read/write facility.
Power voltage: AC220V±10%, 50Hz±10%
Work movement: Germany technology electromagnetic valve
Semi-automatic type: In-built hydraulic shock absorber
Main-board voltage: 12V DC
Passage Width: 550mm
Passing speed in normally open mode: 30~40 persons/min
Passing speed in normally closed mode: 25~30 persons/min
Time of opening / closing: 0.2 seconds
The time required to running state after power on: 5 seconds
MTBF: 550mm
Operation Temperature: -10℃ ~ 70℃
Relative humidity: ≤95% not condensed
Operation environment: Indoor/Outdoor
Input port: relay dry contact signal; +12V level signal and pulse width >100ms, DC12V pulse signal
Communications port: RS232/RS485 electric standard, communications range: ≤1200m. Available to connect with external CAN BUS and Ethernet
Certification: CE
Warranty: 12 months
Net weight: 37KGS

2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod 0
2016 Semi - Automatic Vertical Tripod Turnstile Gate / Turnstile Security Gates / Security Arm Barrier Tripod 1
