Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved

Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved

  • Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved
  • Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved
  • Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved
Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved
Product Details:
Place of Origin: China
Brand Name: RONA
Certification: CE / ISO9001
Model Number: RNCF H5099 / RNCF H5099S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pair
Price: negotiation
Packaging Details: Export Wooden Packing
Delivery Time: 7-15 working days
Payment Terms: , T/T, L/C
Supply Ability: 2000 units Per Month
Contact Now
Detailed Product Description
Material: 304 Stainless Steel Driving Motor: Brushless DC Motor
Size: 1410*170*990 Mm Passage Width: 550 Mm ~1.2m
Temperature: -10°C ~ 50°C Communication Interface: RS 485, Distance ≤1200m
Direction: Single Or Bi-directional Certification:: CE
High Light:

drop arm gate

,

security arm gates

Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved




Product Introduce

RONA Lane is an aesthetically pleasing, barrier free optical turnstile solution for high rise buildings, government centers, education campuses and corporate headquarters. The RONA Lane models are designed and built to withstand a rigorous access control environment while offering graceful passage.



1. Self checking and Alarm Function. Easy for client's maintenace.
2. When power on, arm up automatically. when powe off, arm down automatically.
3. Single or Bi- directional Passing is available.
4. Remote control from PC Terminal.
5. Self resetting : when the turnstile arm down, the user doesn't pass in certain time , it would not allow the user pass.
6. Anti clamping and anti trailing .
7. Counting function



Feature of the Arm drop turnstile:

  • Designed for secure operation with aesthetics in mind
  • Material and finish are 304 Stainless Steel
  • Designer Tops are manufactured from a wide variety of Solid Surface colors, Stainless Steel or Wood to match customer interior design needs
  • Green Arrow / Red "X" LED will light upon acceptance or rejection of credentials
  • Chime will also sound indicating to the user that they may pass
  • Unauthorized attempts and tailgaters will initiate visual and audible alarms
  • 22 infrared photoelectric beams with algorithmic scanning technology that continuously checks each lane for movement allowing for passage of persons with umbrellas, briefcases, etc...
  • Integration with remote alarms, doors, etc...
Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved 0
Parameter of Arm drop turnstile
framework 304 grade stainless steel ,thickness is no less then 1.5mm
specification 1410*170*990 mm
weight 90kg
arms length 510mm
working voltage AC220V ± 10%,50HZ ± 10%
logic voltage 24V
interface one standard port-RS485
transit speed 20-30 persons per minute
working environment indoor /outdoor
working temperature -40 ° c ~ 60 ° c
readable cards IC/ID card
protection grade IP54
opening gate time 1 S
relative humidity ≤ 90%,no -condensation
operating places government agency ,Subway station ,residential area ,school ,enterprise ,factory ,ect.

Bi-directional Drop Arm Turnstile RFID Card Single Pole Turnstile With Anti-Collision CE approved 1
