High-Tech Flap Barrier Gate Intelligent Management For Passages

Name: High-Tech Flap Barrier Gate Intelligent Management For Passages
Brand: Shenzhen Rona Intelligent Technology Co., Ltd
SKU: RNCF F6088
Availability: InStock

Brand Name:	RONA
Model Number:	RNCF F6088
MOQ:	1 unit
Price:	negotiation
Delivery Time:	7-15 work days
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ISO9001

Product Name:

Flap Turnstile

Material:

304 Stainless Steel

Power Supply:

AC220±10%V 50±10%HZ 60W-70W

Dimension:

1200*300*990(mm)

Warranty:

One Year

Color:

Stainless Steel Color(can Be Custom Made)

Packaging Details:

carton and wooden packing

Supply Ability:

2000 unit per month

Highlight:

Flap Barrier Gate for Passages

Intelligent Management Flap Barrier Gate

Product Description

High-Tech Flap Barrier Gate Intelligent Management for Passages

Brief Introduction

Intelligent flap turnstil is a high-tech product which mainly provides intelligent management to passage way. It is a upgrade product of intelligent tripod turnstile and swing barrier. RONA's flap turn stile is finely processed with complete functions and high level,suitable for high-level neighborhoods,intelligent buildings,hotel, subway,port and club,etc.

Single motor:suitable for single passage and multiple passage

Double motor:suitable for multiple passage.

Functions & Features

Anti-pinch function:	Mechanical / infrared Anti-pinch functions (can lead children, drag luggage, backpack, wheelchair through)
Alarm function & Zero self-inspection:	It is convenient for customer to maintain and use
Anti-tailgating:	Somebody enter the gate illegal or Tailgating will trigger alarm
Anti-collision:	Before received the open signal, the turnstile will lock automatically
Automatic Reset Functions:	After open turnstile, during the system time , if you don’t pass the turnstile, the system will cancel your chance to pass the turnstile automatically
One way or two ways passage:	Single or bidirectional optional to control pedestrian enter and exit
Remote control:	Can manager and long-range control the turnstile directly by managing the computer.

Standard Technical parameters

Product size:	L1200W300H990MM
Retractable arm length:	250mm
Max Passage width:	550mm
Material:	SUS 304 stainless steel
Working voltage:	AC220±10%V , 50HZ
Drive motor:	DC24V brushless motor
Input interface:	Dry contact signal & 12V level signal, drive current>10mA
MTBF:	8 million times
Communication interface:	standard RS232 interface
Sensor pairs:	6 pairs
Pass speed:	30 persons/min
Turnstile open/closed time:	1 second
Working environment:	indoor/outdoor (with a tent over) -10℃～70℃
Relative humidity:	≤90% coagulation free

Packaging
