Place of Origin:
China
Brand Name:
RONA
Certification:
CE/ISO9001
Model Number:
RNCF 5008HD
Product Introduction
Turnstiles are used at a wide variety of settings, including stadiums, amusement parks, mass transit stations, office lobbies, airports, ski resorts,factories, power plants and casinos.
From a business/revenue standpoint, turnstiles give an accurate, verifiable count of attendance. From a security standpoint, they lead patrons to enter single-file, so security personnel have a clear view of each patron. This enables security to efficiently isolate potential trouble or to confiscate any prohibited materials. On the other hand, physical barriers become a serious safety issue when a speedy evacuation is needed, requiring emergency exits that bypass any turnstiles.
Standard Features&Functions
(1). Operation model: Both directions can be set as controlled mode or free mode.
(2). NO mode & NC mode can be switched over by users easily & freely.
(3). Tailgating-detection function.
(4). Intruding-alarm function.
(5). Delayed reset automatically function.
(6). Anti-pinch function: protection against finger entrapment and personal injury.
(7). Emergency-escape function: the gates will open automatically by pressing the emergency button which can be remote-controlled whether the power is on or off.
(8). With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of access controllers.
(9). Equipped with free control software for machine interface & control command.
Specifications
| Framework | 304# Stainless Steel |
| Swing arm material | Acrylic (optional) |
| The inductive card reader dimension | equipped with the standard mounting brackets or tailor. |
| Machine center | Germany technological motor |
| Power voltage | AC220V±10%, 50Hz±10% |
| Driver motor | Brushless motor |
| In-built Infrared | 6 pairs |
| Passing speed in normally open mode | 50 persons/min |
| Passing speed in normally closed mode | 30 persons/min |
| Passage Width | 500-1050mm |
| Swinging direction | unidirectional or bi-directional |
| Opening / closing time | 0.1 seconds |
| The time required to running state after power on | 3 seconds |
| Automatic reset time after the failure | 1 seconds |
| Operation temperature | -10℃ ~ +70℃ |
| Relative humidity | less than 95% not condensed |
| Working Environment | Indoor/Outdoor (with rain-tent cover) |
| Input port | relay dry contact signal; +12V level signal, pulse width >100ms, DC12V pulse signal |
| Communications port | RS232/ RS485 electric standard, communications range ≤1200m. Available to connect with external CAN BUS and Ethernet |
Applications
Government Facilities, Corporate Lobbies, Buildings, Banks, Hotel, Super market, Park, Building Sites, Museums and Retail outlets etc.
