RFID Automatic Swing Turnstile Revolving Door Security Access Control Turnstile

RFID Automatic Swing Turnstile Revolving Door Security Access Control Turnstile

RFID Automatic Swing Turnstile

Access Control Revolving Door Turnstile

Security Swing Gate Turnstile 900MM

Place of Origin:

China

Brand Name:

RONA

Certification:

CE/ISO9001

Model Number:

RNCF 3088HD

Contact Us
Request A Quote
Product Details
Product Series:
ZR
Motor Type:
Servo Motor
Main Board Type:
V3.1
Normal Running Life:
10 Million Times
Sensor Quantity:
9 Pairs
Pass Speed:
30 Person/nin
Housing Material:
304 Stailess Steel
Passage Width:
550-900MM
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
negotiation
Packaging Details
carton and wooden packing
Delivery Time
7-15 work days
Payment Terms
L/C, T/T
Supply Ability
2000 unit per month
Product Description

RFID Automatic Swing Turnstile Revolving Door Security Access Control Turnstile



Product Introducting



Intelligent Swing Turnstile is s a high-tech product which mainly provides intelligent management to passageway.This product is finely processed with complete functions and high level.



It is subtly integrated with machine, electronics, micro-processor control and ID identification, provides convenience for the use of card reader identification equipments, such as IC card, ID card, bar code and fingerprint.





It can carry out intelligent control and management to the passageway through choosing various identification equipments and adopting fair, reliable security protection.







Features&Functions

The housing material is 304 stainless steel, it is very durable.



➭Break-in alarm. Trailing alarm.When reverse entry occurs,the gate closes automatically

➭Anti-pinch function, infrared induction anti-pinch function.

➭With standard fire alarm input interface, the device will unconditionally open first after receiving the fire alarm signal.

➭Gate opening and closing time is 0.8~3s.Time required to enter the traffic state after power-on is 3s

➭Anti-collision movement, clutch lock, quiet and efficient

➭The motor type is sensor motor.Use the numerical control encoder to limit, accurate, efficient and low failure rate.

➭With a zero-bit self-inspection function, easy for users to maintain and use.

➭Remote control and management can be realized through the management computer directly.





Technical Parameters



Size: L1400*W200*H1000 mm
Motor type: Servo motor
Main board type: V3.1
Normal running life: 8 million times
Sensor quantity: 9 pairs
Pass speed: 30 person/min
Housing material: 304 stainless steel&Stoving varnish
Passage width: 550-900MM
Swing arm material: Acrylic/Tempered glass/Stainless steel pipe(optional)
Input interface: AC100-240V,50/60HZ
Working voltage: DC24V
Working power: 60W
Working temperature: -15℃-70℃
Working humidity: 5%-90%
Working environment: Indoor/Semi-outdoor(with shade)
Input interface: Relay dry contact signal or 12V pulse signal with pulse width ≥100ms, drive current ≥10mA
