ISO9001 Luxury Speed Gate Turnstile Access Control System For Intelligent Community

ISO9001 Luxury Speed Gate Turnstile Access Control System For Intelligent Community

Access Control System Speedlane Turnstile

Luxury Speed Gate Turnstile

Intelligent Speed Gate Turnstile

Place of Origin:


Brand Name:




Model Number:

RNCF T8008

Contact Us
Request A Quote
Product Details
Housing Material:
304 Stailess Steel
Product Name:
Speed Gate Turnstile
RNCF T8008
One Year
Passage Width:
Less Than 1200mm
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Packaging Details
carton and wooden packing
Delivery Time
7-15 work days
Payment Terms
L/C, T/T
Supply Ability
2000 unit per month
Product Description

ISO9001 Approved Luxury Speed Gate Access Control System For Intelligent Community With 304 stainless steel


Product Introduction

The speed gate is subtly integrated with machine, electronics, micro-processor control and ID identification, provides convenience for the use of card reader identification equipments, such as IC card, ID card, bar code and fingerprint.


It can carry out intelligent control and management to the passageway through choosing various identification equipments and adopting fair, reliable security protection.




  • The housing material is 304 stainless steel, it is very durable.
  • Break-in alarm. Trailing alarm.When reverse entry occurs,the gate closes automatically
  • Anti-pinch function, infrared induction anti-pinch function.
  • With standard fire alarm input interface, the device will unconditionally open first after receiving the fire alarm signal.
  • Gate opening and closing time is 0.8~3s.Time required to enter the traffic state after power-on is 3s.
  • Anti-collision movement, clutch lock, quiet and efficient.
  • The motor type is sensor motor.Use the numerical control encoder to limit, accurate, efficient and low failure rate.
  • With a zero-bit self-inspection function, easy for users to maintain and use.
  • Remote control and management can be realized through the management computer directly.



Technical Parameters


Size: 1400MM*120MM*980MM
Motor type: DC24V brushless motor
Main board type: V2.621
Normal running life: 8 million times
Sensor quantity: 6 pairs
Pass speed: 25-30 person/min
Housing material: 304 stainless steel&Stoving varnish
Passage width: 500-1200MM
Swing arm material: Acrylic/Tempered glass/Stainless steel pipe(optional)
Input interface: AC100-240V,50/60HZ
Working voltage: DC24V
Working power: 100W
Working temperature: -15℃-70℃
Working humidity: 5%-90%
Working environment: Indoor/Semi-outdoor(with shade)
Input interface: Relay dry contact signal or 12V pulse signal with pulse width ≥100ms, drive current ≥10mA
