Automatic Pedestrian Flap Barrier Gate Lake Blue Color With DC24V Brushless Motor

Automatic Pedestrian Flap Barrier Gate Lake Blue Color With DC24V Brushless Motor

Pedestrian Flap Barrier Gate

Lake Blue Flap Barrier Gate

Lake Blue Flap Barrier Turnstile

Place of Origin:

China

Brand Name:

RONA

Certification:

CE/ISO9001

Model Number:

RNCFH 1077

Contact Us
Request A Quote
Product Details
Product Name:
Flap Barrier Gate
Marerial:
304 Stainless Steel
Dimension:
1400mm*310mm*1010mm
Color:
Lake Blue
Direction:
One Or Bi-direction(optional)
Application:
Hotel,Library,Metro Station,etc
Payment & Shipping Terms
Minimum Order Quantity
1 pair
Price
negotiation
Packaging Details
wooden packing
Delivery Time
7-15 work days
Payment Terms
T/T, Western Union
Supply Ability
2000 unit per month
Product Description

Automatic Pedestrian Flap Barrier Gate Lake Blue Color Face Recognition DC24V Brushless Motor



Product describtion

Flap barrier gate is one of the security gates that is used to control crowds automatically. It allows pedestrians to pass in an orderly manner, and refuse unauthorized persons to enter specific areas. Besides, it can be combined with face recognition, fingerprint readers, QR code scanners, and other access control devices.



Flap barrier can be opened and closed quickly,with absolutely no tailgating due to the sensitive photoelectric senso,in addition,the aesthetic design provides a friendly user experience. Therefore, it is now widely used in airports,subway station, fitness centers, amusement parks, construction sites,retail stores, schools, office buildings,etc.



Dimension

Automatic Pedestrian Flap Barrier Gate Lake Blue Color With DC24V Brushless Motor 0





Standard Functions

  •  Alarm function & Zero self-inspection, it is convenient for customer to maintain and use.
  • Turnstile can set the working condition by press the button of main control board.
  •  Anti-pinch function: turnstile have Mechanical / infrared Anti-pinch functions
  • Somebody enter the gate illegal or Tailgating will trigger alarm.
  • Before received the open signal, the turnstile will lock automatically.
  • The retractable arms can be adjustable
  • Automatic Reset Functions: after open turnstile, during the system time , if you don’t pass the turnstile, the system will cancel your chance to pass the turnstile automatically, (reset time is 1~60s you can adjust it what time is suit for you(the system is 10s). Open the turnstile automatically after out of power, closed turnstile automatically after connect the power, totally meet the fire protection needs.
  • The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on.
  •  Single or bidirectional optional to control pedestrian enter and exit.
  • Can manager and long-range control the turnstile directly by managing the computer.



Extended functions

1) LED counting function

2) Voice Prompt and light alarm functions.

3)we can install thermostat in the turnstile during the low temperature region.



Standard Technical parameters



Production side:

L1400*W300*H990MM

Retractable arm length:

250 mm

Max Passage width:

550 mm

Material:

SUS 304 stainless steel

Working voltage:

AC220±10%V , 50HZ

Drive motor:

DC24V brush motor

Input interface:

Dry contact signal & 12V level signal, drive current>10mA

Normal running life:

more than 3 million

Communication interface:

standard RS485 interface

Sensor pairs :

6 pairs

Service port :

window

Pass speed:

30~40 persons/min

Turnstile open / closed time:

1 second

Working environment:

indoor/outdoor (with a tent over) -10℃~70℃

Relative humidity:

≤90% coagulation free





Access Control Management



Automatic Pedestrian Flap Barrier Gate Lake Blue Color With DC24V Brushless Motor 1





Project cases



Automatic Pedestrian Flap Barrier Gate Lake Blue Color With DC24V Brushless Motor 2
