ARMRNCF H8008 - 15 Speed Gates Turnstiles DC24v Pedestrian Vehicle Barriers Automatic

ARMRNCF H8008 - 15 Speed Gates Turnstiles DC24v Pedestrian Vehicle Barriers Automatic

Vehicle Barriers Speed Gates Turnstiles

Automatic DC24v Speed Gates Turnstiles

600mm Speed Gates Turnstiles

Place of Origin:


Brand Name:




Model Number:

RNCFH 8008-15

Contact Us
Request A Quote
Product Details
304 Stainless Steel
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Packaging Details
carton and wooden packing
Delivery Time
7-15 work days
Payment Terms
Supply Ability
2000 Unit Per Month
Product Description

ARMRNCF H8008-15 DC24 Servo Motor Pedestrian Speed Gates Turnstiles and Vehicle Barriers From Automatic Systems


Brief introduction

Intelligent speed gate turnstile is  a high-tech product which mainly provides intelligent management to passageway, its elegance and ability to control large flows of people made it our client’s favourite.It is the ideal product for entrances in prestigious buildings.We offer many other solutions in order to suit different needs.


Name and model:Luxury speed gate /ARMRNCF H8008-15


Arm extension:


Main board kernal:

ARM--M4/32-bit processor

Housing material:304 stainless steel
Passing direction:Single or bi-direction(optional)
Gate opening time:0.6s(optional)
Pass speed:40 persons/min(normolly open)/ 30 persons/min(normally close)
Working voltage:

AC220±10%V/50HZ 100W

Drive motor:

DC24 servo motro,precise control,current anti-pinch

Working environment:

Indoor, out door(with a tent over)-10°C~70°C, Relative humidity:≤90% coagulation free

Normal running life:8 million times
Communication interface:

standard TCP  RS485


 Application(Including but not limited)

  • Examination: candidate identity verification, assisting the invigilator in completing the verification of the candidate's real name identity
  • Bank: opening personal accounts, making large withdrawals, applying for credit cards, and verifying the identity of loan applications
  • Stock  exchange:identity verification of stock and futures loan transactions
  • Airport: handling check-in procedures (ticket purchase, registration) Real name identity verification



1. Memory function
          This equipment can memory more than 2 pcs continuous legal signal (can memory less than 255 pcs legal signal)


2. Second time open function
          if people stand on the sensor area and swiping the card,or people swiping the card but another people enter to the
          sensor area in opposite  side,Result: turnstile will not open, only after people out of the sensor area, the turnstile will
          open again, we called it second time open function.


3. Intelligent anti-pinch function
          We have sensor anti-pinch design / motor torque anti-pinch design /mechanical anti-pinch design, those design to make
          sure passage’s safety when the pass.

4. Automatic reset
          After we swiping the card, during the specified time passenger Don’t pass, the turnstile system will cancel this permission
          and close the gate 1.7 Logical monitoring  9-12 pair sensor (can enlarge to 24 pair sensor), turnstile system will monitor
          the passenger, kids, wheelchair,luggage’s position, and also can warm alarm when have trailing, break in, opposite enter
          illegal action happened

      5. fire alarm function
          Our turnstile can integrate with fire alarm device, during the emergency situation, the turnstile will open automatically to                      provide free passage, but after power on the turnstile will closed automatically again.


    6. Touch screen parameter setting
          This turnstile’s parameter can set by a touch screen device, it is more convenient.
      7. Self -checking
          This turnstile has self-checking function, after the turnstile connect with the touch screen device by cable, we can see
          easily what the problem the turnstile has.


 Other functions which can add

 1. LED display counting functions.

     2. Can enlarge second open function, this function main used for ticket management system or client want anti-feedback


 3. Voice prompt function when passenger pass.

     4.Normal open /close to meet difference requirements in difference project.

     5.Light/voice prompt function.

     6.Flash light prompt to show the manager that the turnstile have problem.

     7. In the low temperature area, this turnstile can add a device to make the turnstile work normally.
