|Place of Origin:||China|
|Certification:||CE / ISO9001|
|Model Number:||RNCF8008X & RNCF8008XS|
|Minimum Order Quantity:||1|
|Packaging Details:||Export Wooden Case Packing|
|Delivery Time:||7-15 working days|
|Payment Terms:||, L/C, T/T|
|Supply Ability:||2000 units Per Month|
|Material:||304 Stainless Steel||Standard Size:||1200mm (L) * 280mm (W) * 990mm (H)|
|Driving Motor:||DC24V Brush Motor||Channel Width:||550mm-1200mm|
|Working Life:||5 Millions||Pass Speed:||30 Persons/min|
SS304 Swing Barrier Turnstile,
Waterproof Swing Barrier Turnstile,
DC24V Swing Turnstile Gate
Swing gate Features
•The lane and passing lights adopt red and green colors to form an overall light effect with the red, green and blue atmosphere lights in the channel, and cooperate with the traffic logic to realize the traffic instructions, and the prompt information is direct and concise;
Swing Gate Parameter
|Material||SUS304 stainless steel|
|Swing gate material||Acrylic/Stainless steel|
|Channel Width||Standard 550mm, max 1200mm|
|Passing Speed||30-35 personal/min|
|Mean Cycles Between Failure||5 million times|
|Output Power||Single Core 50W, dual core 95W|
|Driving Motor||DC brush motor|
|Method of position||Use the encoder to make sure the swing gate position|
|Communication interface||RS485 interface|
|Input / Output signal||dry contact signal input, 6-pair infrared sensor
Applications of swing gate turnstile:
As one of the most widely used turnstile gates, it is mainly used in buildings, offices, communities, schools, and factories. It is used for employees to ride bicycles or electric vehicles, motorcycles, and other places that need to be controlled.
It is suitable for the occasions where the width of the passage is wide, including the occasions where pedestrians or bicycles with luggage parcels are more, and the special passage for the disabled.
Working types of swing gate turnstile
In the swing gate products, there are three working types for users to choose at the entrance and exit: controlled passing, free passing and no passing. Namely there are nine working types for users to choose for one lane in open status and normal close status:
1) Controlled at both entrance and exit: it needs to read card to pass through at both the entrance and exit;
2) Controlled at entrance, free at exit: it needs to read card at entrance, and it does not need to read card at exit to pass through;
3) Controlled at entrance, no passage at exit: it needs to read card at entrance, and no one can pass through at the exit;
4) Free at entrance, controlled at exit: it does not need to read card at entrance to pass through, and it needs to read card at exit to pass through;
5) Free at entrance, free at exit: it does not need to read card at entrance and exit to pass through;
6) Free at entrance, no passage at exit: it does not need to read card at entrance to pass though, and no one is allowed to pass through at exit;
7) No passage at entrance, controlled at exit: no one is allowed to pass through at entrance, and it needs to read card at exit to pass through;
8) No passage at entrance, free at exit: no one is allowed to pass through at entrance, and it does not need to read card at exit to pass through;
9) No passage at entrance, no passage at exit: passage is cut off, and on one is allowed to pass through at both entrance and exit;
Q1: Do you have English version system?
A: Yes, we can provide standard English version system. Also you can use your own system as well.
Q2: Does the equipement include control board?
A: Yes, it is with control board. But if need our system to management, need to order extra channel management control board.
Q3: Can we connect your access control system with our system?
A: Yes, we provide SDK and Software development service with connection port.
Q4: How can we install the turnstiles/barrier gates? Is it easy?
A:Yes, it's easy to install, we have done most of the jobs before sending our products. You just need fix the gates with screws, and connect power supply cables and internet cables.Also we provide one sheet of specific manual specification in the package.
Q5: What is your company’s strength?
A: We are the top 10 manufacturer in turnstile field in China. And we are listed company with famous brand in China.
Q6: How do you do after-sale service?
A: We provide life-time technology support on line, by emails, video, phone etc. We have engineer speaking English, convenient to communicate with you directly.
Q7:How about the lead time?
Normally we have raw material in stock for the hot sale models of standard products. Regular products need 5-7 working days. The customized products need 15-20 working days.
Q8: How many years of warranty?
A: We provide 1 year warranty for our products.
