Place of Origin:
China
Brand Name:
RONA
Certification:
CE / ISO9001
Model Number:
RNCF8008L
Access Control Automatic Stainless Swing Gate Turnstiles For Supermarket /Office
Technical Parameters
| Description | Parameters |
| Item Model | RNCF8008L |
| Service life | ≧5 million cycles |
| Drive voltage | DC24V 20W |
| Pass rate | 30 persons/minute |
| Open direction | Unidirectional and bidirectional (optional) |
| Opening time | 0.6S(adjustable) |
| Humidity | ≤90% coagulation free |
| Thickness of Housing | 2.0mm(optional) |
| Length of the arm | 230-900mm |
| Passage width | 500-1800mm |
| Swing arm work angle | 180° |
| Communication | TCP,IP,RS485 |
Product Description
| 1. Swing Turnstile gate is a device used for pedestrian channel entry/exit management. With quick openning, safety and convenient features, it is the ideal management equipment for pedestrian high frequency access. |
| 2. The device housing are formed by inported SUS#304 stainless steel stamping, beautiful and generous shape, anti-rust, durable. |
| 3. Standard electrical interface for external use, easily integrated with RFID card reader, barcode reader, fingerprint, face recognition, iris recognition etc. |
| 4. Specially designed to meet the fire requirements of the function, convenient for people to evacuate in an emergency. |
| 5. Optical Turnstiles are suit for elegant and luxury entrance solutions. |
Standard functions & features of Swing Turnstiles Gate
| 1. | Infrared sensor to prevent pinch pedestrians. |
| 2. | Alarm function, in case of illegal intrusion and reverse intrusion. |
| 3. | Anti-breakthrough function. The gate is locked automatically until opening signal received. |
| 4. | Anti-trailing function, the turnstile will lock if someone wants to burst in without swiping the RFID card. |
| 5. | The whole system runs smoothly, long-life performance, high operation dependability and fast response. |
| 6. | When power off, optical turnstile will open automatically, which is complying with fire safety requirements. |
| 7. | Automatic reset function. If the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically. |
Adaptive Place
1. Office: Business Building, Government Office, Etc.;
2. Business Services: Supermarkets, Shopping Malls, Hotels, Clubs, Banks, Etc.;
3. Leisure And Entertainment Venues: Parks, Scenic Spots, Amusement Parks, Etc.
4. Transport Site: Bus Station, Railway Station, Subway Station, Airport And So On.
5. Science And Education Unit: Colleges And Universities, Research Institutes, Libraries, Etc.;
