|Place of Origin:||China|
|Certification:||CE / ISO9001|
|Model Number:||RNCF F7008L / RNCF F7008LS|
|Minimum Order Quantity:||1 pair|
|Packaging Details:||Export Wooden Packing|
|Delivery Time:||7-15 working days|
|Payment Terms:||L/C, T/T,|
|Supply Ability:||2000 units Per Month|
|Material:||304 Stainless Steel||Driving Motor:||DC 24 V Brush Motor|
|Working Voltage:||AC220±10%V 50±10%HZ||Normal Running Life:||5millions|
|Material Of Swing:||Acrylic||Input Interface:||+12V Level Signal Or Pulse Width>100ms 12V Pulse, Drive Current>10mA|
|Standard Size:||1600*220*990 Mm||Passage Width:||600-900mm|
|Pass Speed:||25-30 Persons/min|
pedestrian security gates,
pedestrian swing gate
Waterproof Stainless Swing Barrier Gate Kindergarten Swing Motor Electric Turnstiles
1) Swing Barrier Gate is integrating with kindergarten system to guarantee kids security.
2) Visitors enter and exit the Swing Barrier Gate need to show the authorization device , like IC/ID card, barcode paper
3) Visitors enter and exit the Swing Barrier Gate will be take pictures as proof , parents will know when and who pick up the kids.
4) All in all, Swing turnstile will improve kids secuirty in kindergarten, and using this kind of solution can improve kindergarten image.
How to guarantee kids will not be hurt when they using the Swing Barrier Gate ?
1) RONA Swing Barrier Gate using epecial mechanism structure, the strength not enough to hurt them.
2) RONA using high quality infrared , the erroneous judgement almost zero.
3) RONA Swing Barrier Gate can using in outside totaly - Waterproof
Standard functions & features of Swing Barrier Gate
1. Alarm function:when arms are pushed by force illegally, alarm will be triggered automatically and arms will be set locked.
turnstile can check by itself when it is have problem, it is good for customer to maintain and use
2. Turnstile can setting the working condition by press the button of main control board.
3. Anti-pinch function: turnstile have Mechanical/ infrared induction Anti-pinch functions( when it is meet the hinder during the reset time, the electrical machine closed work automatically in specified time, the turnstile will default the delayed and reset again till reset succeed)
4. The turnstile will closed the door when somebody enter the gate illegal, Tailgating or break into negative direction gate.
5. Before received the open signal, the turnstile will lock automatically
6. The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.
7. Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 1~60s you can adjust it what time is suit for you). totally meet the fire protection needs
8. Infrared reset function (Optional:4 pairs or 6 pairs Infrared)
9. Infrared induction clamp function (4 pairs Infrared)
10. The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on
11. The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles)
12. Can manager and long-range control the turnstile directly by managing the computer.
13. Flashing light prompt function: it is convenient to find the turnstile problem by administrative staff
|1. LED counting function||2. Size customization|
|3. Add more infrared||4. Program customization (for example : Normally open or closed can be adjust to meet the requirements of the different place. )|
|5. Voice Prompt Function|
