Place of Origin: | China |
Brand Name: | RONA |
Certification: | CE/ISO9001 |
Model Number: | RNCFH 8008-13 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiation |
Packaging Details: | carton and wooden packing |
Delivery Time: | 7-15 work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 2000 unit per month |
Size: | 1500mm*150mm*990mm | Motor Type: | Servo Motor |
---|---|---|---|
Main Board Type: | ARM Controller | MTBF: | 10 Million Times |
Sensor Quantity: | 10 Pairs | Pass Speed: | 30 Persons/min |
Housing Material: | 304 Stailess Steel&Stoving Varnish | Passage Width: | 550mm-1050mm |
High Light: | Access Control Speed Gate Turnstile,DC Servo Motor Speed Gate Turnstile,Baking Varnish Aluminum Access Control Turnstile |
Product Introduction
Turnstiles are used at a wide variety of settings, including stadiums, amusement parks, mass transit stations, office lobbies, airports, ski resorts,factories, power plants and casinos.
From a business/revenue standpoint, turnstiles give an accurate, verifiable count of attendance. From a security standpoint, they lead patrons to enter single-file, so security personnel have a clear view of each patron. This enables security to efficiently isolate potential trouble or to confiscate any prohibited materials. On the other hand, physical barriers become a serious safety issue when a speedy evacuation is needed, requiring emergency exits that bypass any turnstiles.
Standard Features&Functions
(1). Operation model: Both directions can be set as controlled mode or free mode.
(2). NO mode & NC mode can be switched over by users easily & freely.
(3). Tailgating-detection function.
(4). Intruding-alarm function.
(5). Delayed reset automatically function.
(6). Anti-pinch function: protection against finger entrapment and personal injury.
(7). Emergency-escape function: the gates will open automatically by pressing the emergency button which can be remote-controlled whether the power is on or off.
(8). With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of access controllers.
(9). Equipped with free control software for machine interface & control command.
Specifications
Framework | 304# Stainless Steel |
Swing arm material | Acrylic (optional) |
The inductive card reader dimension | equipped with the standard mounting brackets or tailor. |
Machine center | Germany technological motor |
Power voltage | AC220V±10%, 50Hz±10% |
Driver motor | Servo motor |
In-built Infrared | 10 pairs |
Passing speed in normally open mode | 50 persons/min |
Passing speed in normally closed mode | 35 persons/min |
Passage Width | 600mm |
Swing arm transmission angle | 180° |
Swinging direction | unidirectional or bi-directional |
Opening / closing time | 0.1 seconds |
The time required to running state after power on | 3 seconds |
Automatic reset time after the failure | 1 seconds |
Mean time to failure | min. 10 000 000 |
Operation temperature | -10℃ ~ +70℃ |
Relative humidity | less than 95% not condensed |
Working Environment | Indoor/Outdoor (with rain-tent cover) |
Input port | relay dry contact signal; +12V level signal, pulse width >100ms, DC12V pulse signal |
Communications port | RS232/ RS485 electric standard, communications range ≤1200m. Available to connect with external CAN BUS and Ethernet |
Applications
Government Facilities, Corporate Lobbies, Buildings, Banks, Hotel, Super market, Park, Building Sites, Museums and Retail outlets etc.
