304 Stainless Steel​ Drop Arm Barrier Gate Two Way Assemble Access Control

304 Stainless Steel​ Drop Arm Barrier Gate Two Way Assemble Access Control

  • 304 Stainless Steel​ Drop Arm Barrier Gate Two Way Assemble Access Control
304 Stainless Steel​ Drop Arm Barrier Gate Two Way Assemble Access Control
Product Details:
Place of Origin: China
Brand Name: RONA
Certification: CE / ISO9001
Model Number: RNCF2099 / RNCF2099S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pair
Price: negotiation
Packaging Details: Export Wooden Packing
Delivery Time: 7-15 working days
Payment Terms: , T/T, L/C
Supply Ability: 2000 units Per Month
Contact Now
Detailed Product Description
Material: 304 Stainless Steel Driving Motor: Brushless DC Motor
Size: 185*175*1080 Mm Reader Windows:: 2 RFID Readers
Power Consumption:: 35w Work Environment: Indoor & Outdoor
System Integration: Yes
High Light:

drop arm gate

,

security arm gates

304 stainless steel​ Drop Arm Turnstile Two Way Assemble Access Control with CE approved


Feature of the Arm drop turnstile:

1) NO mode & NC mode can be switched over by users easily & freely.
2) Self-recovery function: the machine will recovery automatically with invalid counting if passage
is not completed within pre-set time (5 seconds default, adjustable by software).
3) Self-examine Function: it is convenient for users to maintain and use.
4) Tailgating-detection function.
5) Intruding-alarm function.
6) Anti-pinch function: protection against finger entrapment and personal injury.
7) Emergency-escape function: the obstacles will open automatically by pressing the emergency button which can be remote-controlled whether the power is on or not.
8) With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of acces controllers.
9) Each machine can be set by Physical Address (Optional).
10) Equipped with free control software for man-machine interface & control command SDK.



Product introduce

1) Arm drop turnstile is a high-tech product which mainly provides intelligent management to passageway, and is the upgrade product of intelligent tripod turnstile and swing barrier. Like swing barrier, this product is finely processed with complete functions and high level, suitable for high-level neighborhoods, intelligent buildings, hotel, subway, port and club those high-level places.

2) This equipment is subtly integrated with machine, electronics, micro-processor control and ID identification, provides convenience for the use of card reader identification equipments, such as IC card, ID card, bar code and fingerprint. It can carry out intelligent control and management to the passageway through choosing various identification equipments and adopting fair, reliable security protection, alarming equipment and direction indicating equipments..

3)Classified into two kinds: single motor (suitable for single passageway and multiple passageway.);

Double motors (suitable for multiple passageways


Parameter of Arm drop turnstile

Model Number

RNCF5099
Dimension 185*175*1080 mm

Housing Material

304# Stainless Steel

Arm Length
≤600 mm

Passing Speed
30-40 persons/min(RFIDCard)

Direction

Single way or double way

Operating temperature

minus 40°C---60°C

Relative Humidity

≤95%, No Condensation

Power
AC220C±10V,50HZ

Motor
30W/24V

Working power

DC24V 12AH

Communication Connection

TCP/IP

Running Life

5--8 Millions

Opening/Closing time
1 second

Self checking time
3s

Certificates

CE and ISO9001

Protection level
IP54


304 Stainless Steel​ Drop Arm Barrier Gate Two Way Assemble Access Control 0
