Place of Origin:
China
Brand Name:
RONA
Certification:
CE/ISO9001
Model Number:
RNCF 7088C
Product Usage
| Access Management: | Pedestrian access gates can effectively manage and control the entry and exit of personnel by setting different permissions and access methods.Prevent unauthorized personnel from entering. |
| Records Management: | Pedestrian access gates can record the passage records of each user, including passage time, passage direction and other information, which can provide support for subsequent data analysis and management. |
| Security Monitoring: | Pedestrian passage turnstiles have intelligent security monitoring functions, which can carry out identification and security monitoring of passers-by Control, prevent criminals from entering, and ensure the safety of the place. |
| Energy saving and environmental protection: | The pedestrian gate adopts energy-saving design, which can effectively reduce energy consumption and reduce the energy cost of enterprises, which has positive significance for environmental protection. |
Functions&Features
304 stainless steel, national standard 1.5MM precision machining
6 pairs of industrial grade sensors, long-life for use.
Infrared and electric current anti-pinch for protecting traffic safety
A variety of traffic modes can be adjusted to meet the needs of the scene
Anti-collision movement, clutch lock, quiet and efficient
Trailing, reverse traffic alarm, prompt function
One-to-one master control, durable
CE,ISO9001 certification
Parameters
| Size: | L1400*W300*H990 mm |
| Retractable arm length: | 250 mm |
| Max Passage width: | 550 mm |
| Material: | SUS 304 stainless steel |
| Working voltage: | AC220±10%V , 50HZ |
| Drive motor: | DC24V brush motor |
| Input interface: | Dry contact signal & 12V level signal, drive current>10mA |
| Normal running life: | More than 3 million |
| Communication interface: | Standard RS485 interface |
| Sensor pairs : | 6 pairs |
| Pass speed: | 30~40 persons/min |
| Turnstile open / closed time: | 1 second |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
| Relative humidity: | ≤90% coagulation free |
