Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor

Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor

    • Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor
    • Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor
    • Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor
  • Full Height Sliding Barrier Gate , Access Control Barrier 220V AC Servo Motor

    Product Details:

    Place of Origin: China
    Brand Name: RONA
    Certification: CE / ISO9001
    Model Number: RNCF4066

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Lane
    Price: negotiation
    Packaging Details: carton and wooden packing
    Delivery Time: 7-15 working days
    Payment Terms: T/T, Western Union
    Supply Ability: 2000 units Per Month
    Contact Now
    Detailed Product Description
    Driver Motor: 220V AC Servo Motor Passage Width: 600mm~900mm
    Working Voltage: AC220V±10%, 50Hz±10% Materials: 304# Stainless Steel/Acrylic/Tempered Glass
    Passing Speed: 30~40 Persons/min

    Full height servo sliding gate turnstile access control turnstile



    Functions and Features of the sliding gates :



    • When power off, arm open automatically and power on again, arm will be held automatically.
    • When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel.
    • Auto-reposition function: After card read, passenger not pass within regulated time period, full-height turnstile will cancel this passing right. And the regulated time period for passing can be set by managers.
    • If passenger pass without card read or valid card read, flap barrier will alarm untill passenger get back from the flap barrier and then take a valid card to be read for passing.
    • Flap barrier is with 485 interface for long-distrance control concern.
    • Anti-rush function: if there is no open single, arm will be holding tightly.
    • Double anti-clipping function: photocell anti-clipping and mechanical anti-clipping.When passenger is going through the flap barrier, photocell will detect out this situation and will not close. After passenger passed, arm will close automatically. During its reposition, if arm meets any obstacle, arm will get back automatcially or stop working for a while with very slight force. Also it will alarm.

    Specification:

    Structure frame structure/standard stainless steel shell
    Production full CNC laser cutting machine production
    Dimension 1406*300*1023mm
    Maximum channel width 600mm
    N.W. 110KG
    Power 50W
    Drive motor stepping motor
    Power on state require time 3 seconds
    Failure automatically reset time 10 seconds
    Passing speed <=40 persons/min
