Office Building Automatic Swing Gates Solution For Visit Management System

Office Building Automatic Swing Gates Solution For Visit Management System

    • Office Building Automatic Swing Gates Solution For Visit Management System
    • Office Building Automatic Swing Gates Solution For Visit Management System
  • Office Building Automatic Swing Gates Solution For Visit Management System

    Product Details:

    Place of Origin: China
    Brand Name: RONA
    Certification: CE / ISO9001
    Model Number: RNCF H8008-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Lane
    Price: negotiation
    Packaging Details: carton and wooden packing
    Delivery Time: 7-15 working days
    Payment Terms: T/T, Western Union
    Supply Ability: 2000 units Per Month
    Contact Now
    Detailed Product Description
    Materials: 304# Stainless Steel Finish: Brushed Surface/polishing Surface
    Dimension: Φ141mm*H1005mm Power Voltage: AC220V±10%, 50Hz±10%
    Driver Motor: DC Servo Motor Passing Speed: 40 Persons/min
    Passage Width: 600mm Operation Temperature:: -10℃ ~ +70℃

    Speed Gate Turnstile gate With 304# Stainless Steel for visit management system solution office building



    PRODUCT DESCRIPTIONS:

    • -> The RNCF H8008-5 luxury speed gate pursues a combination of artistic and modern elements, and it is very ideal for elegant location.

    • -> The luxury speed gate has a wide passage width to accomodate pedestrians, users with luggage or -> -> package and bicycles.

    • -> The luxury speed gate integrates machinery, electronics, microprocessor control and a variety of identification technologies, conveniently compatible with access control systems, barcode cards and biometric equipment.

    • -> The luxury speed gate provides a high level of security and high capacity by adopting reliable security protection devices, alarm devices, direction indicators etc.



    STANDARD FEATURES & FUNCTIONS:

    • (1). Operation model: Both directions can be set as controlled mode or free mode.

    • (2). NO mode & NC mode can be switched over by users easily & freely.

    • (3). Tailgating-detection function.

    • (4). Intruding-alarm function.

    • (5). Delayed reset automatically function.

    • (6). Anti-pinch function: protection against finger entrapment and personal injury.

    • (7). Emergency-escape function: the gates will open automatically by pressing the emergency button which can be remote-controlled whether the power is on or off.

    • (8). With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of access controllers.

    • (9). Equipped with free control software for machine interface & control command SDK.



    SPECIFICATIONS:



    Framework

    304# Stainless Steel (default), 201# or 316# Stainless Steel or paint (optional)

    Thickness of ply

    1.7mm

    Finish

    brushed surface, polishing surface

    Shell's size (L*W*H)

    Φ141mm*H1005mm (default)

    Swing arm material

    Tempered glass or Acrylic (optional)

    Stretching out swing length

    260mm~600mm

    The inductive card reader dimension

    equipped with the standard mounting brackets or tailor.

    Machine center

    Germany technological motor

    Power voltage

    AC220V±10%, 50Hz±10%

    Driver motor

    DC36 servo motor

    Main-board voltage

    12V DC

    In-built Infrared

    6 pairs/passageway

    Passing speed in normally open mode

    50 persons/min

    Passing speed in normally closed mode

    40 persons/min

    Passage Width

    600mm

    Swing arm transmission angle

    180°

    Swinging direction

    unidirectional or bi-directional

    Opening / closing time

    0.1 seconds

    The time required to running state after power on

    3 seconds

    Automatic reset time after the failure

    1 seconds

    Mean time to failure

    min. 5 000 000

    Operation temperature

    -10℃ ~ +70℃

    Relative humidity

    less than 95% not condensed

    Working Environment

    Indoor/Outdoor (with rain-tent cover)

    Input port

    relay dry contact signal; +12V level signal, pulse width >100ms, DC12V pulse signal

    Communications port

    RS232/ RS485 electric standard, communications range ≤1200m. Available to connect with external CAN BUS and Ethernet



    APPLICATIONS:

    Typical areas of application are: Government Facilities, Corporate Lobbies, Buildings, Banks, Hotel, Super market, Park, Building Sites, Museums and Retail outlets etc.
